Oil Impregnation Process
How Sintered Bearings Hold Oil — A practical guide to how porous PM bearings store oil, release it during operation, and where oil impregnation adds real value in self-lubricating bearing programs

Yao Qingpu
Powder Metallurgy Manufacturing Expert at SinterWorks PM
Table of Contents
Quick Answer
Oil impregnation fills the connected pores of a sintered bearing with lubricating oil after pressing and sintering. A typical self-lubricating PM bearing holds 18–25% interconnected porosity by volume; vacuum or thermal impregnation fills most of that pore network with oil. During operation, heat and shaft motion draw a thin film onto the running surface; when the shaft stops, capillary action pulls the oil back into the pores.
Key Takeaways
- Oil impregnation depends on controlled interconnected porosity — typically 18–25% by volume in self-lubricating PM bearings
- Vacuum impregnation is the quality benchmark for consistent oil fill; thermal soaking is faster and adequate for many standard bearings
- Oil impregnation should usually be the last value-added step before packaging — machining after impregnation complicates handling
- Published PV limits exist for a reason: beyond the design envelope the film demand outruns the reservoir
- Oil-impregnated PM bearings dominate light-to-moderate duty where maintenance access is poor and volume makes unit cost matter
# Oil Impregnation Process in Sintered Bearings
Quick Answer
Oil impregnation fills the connected pores of a sintered bearing with lubricating oil after the bearing has been pressed and sintered. A typical self-lubricating PM bearing holds 18–25% interconnected porosity by volume, and vacuum or thermal impregnation fills most of that pore network with oil. During operation, heat and shaft motion draw a thin film of that stored oil onto the running surface; when the shaft stops, capillary action pulls the oil back into the pores. That reservoir-and-release cycle is what lets a porous bronze or iron bushing run for years without external lubrication.
Introduction
Oil impregnation is the step that turns a porous sintered bearing into a practical self-lubricating component.
Without it, the part is simply porous metal. After impregnation, the connected pore structure becomes a built-in lubricant reservoir — which is why oil-impregnated bearings show up in motors, fans, pumps, and appliances by the hundreds of millions. For material grades, shapes, sizes, and PV selection, see our self-lubricating bearings guide.
Search interest in "oil impregnation process" usually comes from two directions: engineers checking whether a sintered bearing can survive their duty cycle without a grease fitting, and buyers trying to understand why the same bushing costs less than a machined-and-greased alternative. This guide answers both — how the process works step by step, how much oil a bearing actually holds, and where the limits are.
What Oil Impregnation Means in Powder Metallurgy
Oil impregnation is the process of filling the interconnected porosity of a sintered part with lubricating oil.
It only works because press-and-sinter PM bearings are intentionally porous. During compaction and sintering, the part develops a stable network of connected voids instead of reaching full density. That pore network is the reservoir.
In plain terms:
- The bearing is pressed and sintered with controlled internal voids
- Those voids are filled with oil after sintering
- The stored oil feeds the bearing surface during operation
- Capillary forces recover the oil when the shaft stops
This is fundamentally different from a fully dense machined bushing with grease grooves. A machined bushing stores lubricant on the part; an oil-impregnated bearing stores it inside the part.
Why Porosity Is the Key Design Variable
In most manufacturing discussions, porosity is a defect. In self-lubricating bearings, it is a specified feature — and the single most important design variable. The same engineered pore networks, tuned for permeability rather than oil storage, are what make sintered metal filters work as rigid, cleanable filtration media.
The pore structure determines:
- Oil capacity — more interconnected porosity means a larger reservoir
- Oil release rate — pore size and connectivity control how readily oil migrates to the surface
- Mechanical strength — more porosity means less load-bearing metal; the tradeoff is direct
Standard self-lubricating bearings run 18–25% interconnected porosity by volume, with the classic tin-bronze sleeve bearing typically near the middle of that range. Higher porosity stores more oil but carries less load; lower porosity carries more load but runs the reservoir dry sooner under demanding duty.
Two details matter more than the headline percentage:
- Interconnected vs closed porosity. Only connected pores accept and release oil. Sintering practice controls this; a bearing can show 20% total porosity yet hold far less usable oil if much of it is closed.
- Pore size distribution. Very fine pores hold oil tightly (good against leakage, slower release); coarser pores release readily but can weep oil in storage. Bearing grades are engineered around this balance.
The Oil Impregnation Process, Step by Step
Factory routes vary, but production oil impregnation follows the same logic: get air out of the pores, get oil in, then verify the fill.
| Step | Operation | Purpose | Typical Practice |
|---|---|---|---|
| 1 | Compaction | Form bearing geometry with controlled porosity | Die compaction of bronze or iron-based powder to target green density |
| 2 | Sintering | Bond particles, set the pore network | Controlled-atmosphere furnace; time/temperature tuned to the porosity spec |
| 3 | Sizing (optional) | Calibrate bore/OD before impregnation | Coining or sizing operation; done first because oil complicates later handling |
| 4 | Cleaning & preparation | Remove contaminants, free the pore network | Degreasing and drying so pores are open and oil-wettable |
| 5 | Oil filling | Displace air from pores with lubricant | Vacuum impregnation (evacuate parts, flood with oil, release vacuum so pressure drives oil in) or thermal impregnation (hot oil soak lowering viscosity and expanding trapped air out) |
| 6 | Drain & surface removal | Remove excess surface oil | Drain, often with centrifuging; surface film removed while pore oil is retained |
| 7 | Verification | Confirm oil content and condition | Oil content checked gravimetrically (weight before/after); sampling per batch |
Why vacuum impregnation is the quality benchmark: simply soaking parts in oil leaves air pockets trapped in fine pores. Pulling a vacuum first collapses the air volume, and re-admitting atmospheric pressure on top of the oil bath drives oil into pores that soaking cannot reach. Thermal soaking alone is faster and adequate for many standard bearings; vacuum filling is preferred when oil content consistency is critical — quiet-running motor bearings being the classic case.
A process note buyers should know: oil impregnation is usually the last value-added step before packaging. Machining or sizing after impregnation smears oil, contaminates coolant, and burns out the benefit. If your drawing needs post-impregnation machining, flag it in the DFM review — the sequence can be engineered around it, but it changes cost.
How the Stored Oil Actually Lubricates
The mechanism is elegant and worth understanding because it explains the operating limits:
- At rest: oil sits in the pore network, held by capillary forces
- At startup: shaft motion and frictional heating reduce oil viscosity and expand the oil slightly; a thin film migrates onto the running surface
- At speed: the bearing runs on a continuously replenished micro-film; hydrodynamic lift may develop at favorable speed/load combinations
- At shutdown: the surface film cools and is drawn back into the pores by capillarity, ready for the next cycle
The practical consequence: the bearing lubricates itself as long as the reservoir holds and the duty cycle stays within the design envelope. Push load, speed, or temperature beyond the design point and the film demand outruns the reservoir's ability to supply — which is why published PV (pressure × velocity) limits for sintered bearings exist and should be respected.
How Much Oil Can a PM Bearing Hold?
As a working rule: oil content by volume typically reaches 18–25% of the bearing's total volume after full impregnation of a standard-porosity bearing — in other words, most of the interconnected pore space is filled, and oil is retained well enough that properly packaged bearings arrive with their full charge.
What that means in service terms:
- Service interval: in favorable motor and fan duty (moderate load, moderate speed, controlled temperature), a correctly sized oil-impregnated bearing commonly runs its design life — frequently the full appliance life — with no relubrication
- Life-limiting factor: oil is gradually lost through the running surface and by oxidation at elevated temperature; the bearing "wears out" lubricant-wise long before it wears out mechanically in many light-duty applications
- Temperature penalty: sustained high temperature accelerates both oil loss and oil degradation; continuous service above roughly 70–90°C (oil-dependent) should trigger a design review of oil type and expected life
If your application needs longer life or harsher duty, options include higher-porosity designs, premium synthetic oils, re-impregnation provisions in the assembly, or supplementary lubrication — all of which are legitimate engineering answers, not admissions of weakness.
Where Oil-Impregnated Bearings Fit: Application Comparison
| Application | Typical Duty | Why Oil-Impregnated PM Wins | Watch Out For |
|---|---|---|---|
| Small electric motors (fans, blowers) | Continuous, light load, moderate speed | Silent operation, life-of-appliance lubrication, compact design | Motor heating raising bearing temperature; oil grade selection |
| Home appliances (washers, dryers) | Intermittent, oscillating, humid environment | No grease to wash out or contaminate; corrosion-resistant bronze options | Water/detergent ingress flushing the oil film |
| Automotive accessory (actuators, small pumps) | Cyclic, under-hood temperature swings | Wide oil-type options, high-volume cost advantage | Temperature extremes degrading standard oils — specify synthetic |
| Power tools | High speed, shock loading, intermittent | Instant lubrication at startup, compact packaging | High PV duty approaching sintered bearing limits — validate |
| Office / consumer electronics | Very light load, quiet-critical | Lowest-noise bearing solution available, zero maintenance | Cost pressure pushing porosity too high and strength too low |
| Industrial pumps & valves | Continuous, fluid-adjacent | Compatible with many process fluids when oil is selected correctly | Process fluid washing or contaminating the charge oil |
The pattern: oil-impregnated PM bearings dominate wherever loads are light-to-moderate, access for maintenance is poor or impossible, and volumes make per-part cost matter. Heavy shock loads, very high PV duty, and abrasive contamination are where rolling bearings or externally lubricated bushings take over.
Design Questions to Review Before Release
Before you release a drawing for oil-impregnated PM bearings, run through these:
- PV duty: is your pressure × velocity within published limits for the bearing grade — with margin for the worst case, not the nominal case?
- Porosity vs strength: does the specified porosity carry your maximum load with an acceptable safety factor?
- Oil selection: standard mineral oil, or does temperature/duty justify a synthetic? (This is a cost line, but a small one relative to field failure.)
- Shaft condition: sintered bearings are forgiving, but shaft roughness and hardness still set wear rate — specify them
- Housing fit: press-fit practice affects bore closure; the installed bore — not the free-state bore — is what the shaft sees
- Contamination path: can dust, water, or process fluid reach the bearing? Sealed or flanged variants exist for a reason
- Post-impregnation operations: anything that machines, heats, or solvent-cleans the bearing after oil filling needs to be engineered, not assumed
Oil Impregnation Standards and Specs (ASTM B438)
When an oil-impregnated bronze bearing is specified on a drawing in North American practice, the reference standard is ASTM B438. Reading its grade/type grid is the fastest way to communicate exactly what you need — and to check what any supplier is actually offering.
Grades and types. B438 organizes materials along two axes. Three composition grades are separated by graphite content: Grade 1 at 0–0.3%, Grade 2 at 0.5–1.8%, and Grade 3 at 2.5–5.0%. A Type 1–4 density ladder then runs from 5.8–6.2 g/cm³ up to 7.2–7.6 g/cm³. The classic 90/10 oil-impregnated bronze is Grade 1, with a composition window of Cu 87.2–90.5%, Sn 9.5–10.5%, and graphite ≤0.3%.
What the standard requires of the oil. For the workhorse Grade 1 Type II material, B438 sets a minimum oil content of 19 vol% — the floor behind the 18–25 vol% practical window quoted throughout this guide. At the low-density end, Grade 1 Type I must hold at least 27 vol% oil, and its 6.2 g/cm³ density ceiling exists specifically to preserve the connected porosity that the 27% fill depends on. When a drawing cites only "sintered bronze per B438", the default expectation is the Grade 1 Type II combination — stating grade and type explicitly prevents a higher-density, lower-oil variant from being substituted.
Tolerances and adjacent standards. Dimensional control follows ISO 4379 for sintered plain bearings: OD tolerance bands s6/r6, an H7 housing bore, and a bearing bore supplied at E6 that closes to H8 after press-in. Our sintered bushing installation guide walks through that press-fit chain step by step. B438 itself covers bronze-base bearings only — iron-base oil-impregnated bearings fall under ASTM B439, and we cover the ferrous grade family separately on the FC-0205 iron-copper material page.
Oilite-Style Bearings: Terminology, Maintenance, and Real-World Fit
A trademark with engineering history. "Oilite" is not a generic material code — it is a trademark. The material was developed in 1930 by a Chrysler engineering team (Carl Breer, Frank Sherwood, and Bill Caulkins) from an original composition of 88.5% Cu, 10% Sn, and 1.5% graphite at roughly 25% volume porosity. Super Oilite followed in 1932. Since 1965 the trademark has belonged to Beemer Precision Inc. of Pennsylvania, USA, whose UK partner Bowman International serves as Europe's exclusive genuine Oilite supplier.
Generic use vs. genuine product. Like a handful of older industrial brands, the name has slipped into generic use: many engineers say "oilite bushing" to mean any sintered bronze oil-impregnated bushing, while genuine Oilite products come only from Beemer's network. In practice, a buyer searching for "oilite" usually needs a sintered bronze bearing at the ASTM B438 Grade 1 Type II level — and a PM manufacturer producing to that specification supplies a functionally equivalent part, made to print. The material science is public; the trademark covers the name.
Maintenance-free is not infinite-life. The oil charge depletes slowly through film loss, evaporation, and heat cycling. When friction noise rises, or after sustained high-temperature exposure, bearings can be re-oiled: a low-temperature bake followed by an oil soak restores most of the charge, and vacuum equipment helps but is not required. Timing and procedure are covered in the bronze self-lubricating bearings material page and the installation guide above.
Fit boundaries. Respect the PV envelope, distinguish oscillating from continuous rotation when sizing, and remember that the first seconds after startup run on boundary lubrication before the film establishes — statistically the highest-wear moments of the bearing's life.
Frequently Asked Questions
What is oil impregnation in a sintered bearing? It is the process step where lubricating oil is introduced into the connected pore network of a sintered bearing — typically by vacuum or thermal impregnation — so the bearing can store and release its own lubricant during operation.
How much oil can a PM bearing hold? A standard self-lubricating PM bearing with 18–25% interconnected porosity typically holds oil equal to roughly 18–25% of its total volume after full impregnation. That reservoir commonly supports life-of-appliance service in light-to-moderate duty without relubrication.
Why can sintered bearings hold oil but machined bushings cannot? Sintered bearings are intentionally porous — their internal voids are connected and oil-wettable. A fully dense machined bushing has no pore network, so it can only carry lubricant on its surface or in grooves, which requires periodic re-lubrication.
Does oil impregnation mean the bearing never needs maintenance? In favorable duty — moderate load, speed, and temperature — oil-impregnated bearings routinely run the appliance's full design life without attention. Harsh duty (high PV, high temperature, contamination) shortens oil life, and those applications should be validated rather than assumed.
Can oil-impregnated bearings be re-oiled? Yes. Bearings can be re-impregnated by soaking in heated oil, and some assemblies are designed with re-oiling provisions or felt wicks that extend service life. It is far cheaper to size the initial oil charge correctly than to plan on field re-oiling.
When is oil impregnation the wrong choice? Very high PV duty, heavy shock loading, abrasive environments without sealing, and applications where oil contamination of the product is unacceptable (some food or textile equipment) are all cases for other bearing solutions. A good supplier will tell you when your application crosses that line.
What does "Oilite" actually mean, and is every oil-impregnated bearing an Oilite?
Oilite is a trademark, not a material class. It was developed in 1930 by a Chrysler engineering team and has belonged to Beemer Precision Inc. since 1965. In everyday use the name has become generic shorthand for sintered bronze oil-impregnated bushings, but genuine Oilite products come only from Beemer's network. What most buyers want under the "oilite" name is functionally an ASTM B438 Grade 1 Type II bearing — a specification any PM supplier can produce and verify against.
How much oil does a sintered bronze bearing hold, by standard?
ASTM B438 Grade 1 Type II requires a minimum oil content of 19 vol%. Typical interconnected porosity — and with it the practical oil-content window — runs 18–25 vol%, and the lower-density Grade 1 Type I material is specified at about 27 vol%.
Can you re-oil a sintered bearing in the field, and when?
Yes. Re-oil when friction noise rises, after sustained high-temperature exposure, or at a scheduled overhaul in high-PV duty. The field procedure is a low-temperature bake to open the pores followed by a heated oil soak; vacuum equipment improves saturation but is not required. The sintered bushing installation guide covers the full sequence.
Related Resources
- Oil-Impregnated Bearings (Product) — standard and custom self-lubricating bearing programs
- Bronze Self-Lubricating Bearings (Material) — the classic porous bronze bearing material
- Iron-Graphite Bearings — the ferrous alternative for higher loads
- Oil-Impregnated vs Bronze Bushings — a direct material-route comparison
- Advantages and Disadvantages of Powder Metallurgy — where controlled porosity fits the bigger PM picture
- Sintered Metal Filters (Product) — engineered porosity applied to industrial filtration
Specifying an Oil-Impregnated Bearing?
Send your shaft size, load, speed, temperature, and annual volume through our quote form. We will come back with a porosity and oil recommendation — including an honest answer if your duty cycle belongs to a different bearing technology.
Related Resources
Use these internal guides to keep exploring process planning, materials, quality control, and quoting steps for this topic.
What Are Oil-Impregnated Bearings? Benefits, Materials, and Applications
Learn what oil-impregnated bearings are, how porous self-lubricating bushings work, which materials are commonly used, and where they are most effective in motors, pumps, appliances, and compact drive systems.
Powder Metallurgy Materials Guide
Compare common PM material families, density ranges, and application fit before locking your specification.
Secondary Operations for Powder Metallurgy Parts: When and How to Use Them
Learn when secondary operations are needed for PM parts, including sizing for tighter tolerances, machining for precision features, heat treatment for hardness, and surface treatments for durability.
What Is Powder Metallurgy? Process, Benefits, Materials, and Applications
Learn what powder metallurgy is, how the PM process works, what materials it uses, and why it is often chosen for high-volume precision metal parts with low material waste.
Frequently Asked Questions
What is oil impregnation in a sintered bearing?
It is the process step where lubricating oil is introduced into the connected pore network of a sintered bearing — typically by vacuum or thermal impregnation — so the bearing can store and release its own lubricant during operation.
How much oil can a PM bearing hold?
A standard self-lubricating PM bearing with 18–25% interconnected porosity typically holds oil equal to roughly 18–25% of its total volume after full impregnation. That reservoir commonly supports life-of-appliance service in light-to-moderate duty without relubrication.
Why can sintered bearings hold oil but machined bushings cannot?
Sintered bearings are intentionally porous — their internal voids are connected and oil-wettable. A fully dense machined bushing has no pore network, so it can only carry lubricant on its surface or in grooves, which requires periodic re-lubrication.
Does oil impregnation mean the bearing never needs maintenance?
In favorable duty — moderate load, speed, and temperature — oil-impregnated bearings routinely run the appliance's full design life without attention. Harsh duty (high PV, high temperature, contamination) shortens oil life, and those applications should be validated rather than assumed.
Can oil-impregnated bearings be re-oiled?
Yes. Bearings can be re-impregnated by soaking in heated oil, and some assemblies are designed with re-oiling provisions or felt wicks that extend service life. It is far cheaper to size the initial oil charge correctly than to plan on field re-oiling.
When is oil impregnation the wrong choice?
Very high PV duty, heavy shock loading, abrasive environments without sealing, and applications where oil contamination of the product is unacceptable (some food or textile equipment) are all cases for other bearing solutions. A good supplier will tell you when your application crosses that line.
