Quick Answer
FC-0208 is an iron-copper powder metallurgy grade — about 2% copper and 0.8% combined carbon — used for structural parts such as gears, brackets and small housings. Density sets the properties: 6.6–6.8 g/cm³ is the cost-driven band, 6.9–7.1 g/cm³ covers most structural work, and higher density lifts tensile strength and hardness. It sinters in a standard furnace and machines well.
Introduction
Readers often arrive asking what iron and copper make together, or whether iron is stronger than copper: in PM the answer is the iron-copper family, where copper is the alloying addition and the iron matrix carries the load.
FC-0208 is one of the most widely used iron-copper powder metallurgy materials, offering an excellent balance of strength, machinability, and cost-effectiveness for medium-duty structural components. The designation indicates:
- F = Ferrous (iron-based)
- C = Copper alloying element
- 02 = 2% copper content (nominal)
- 08 = 0.8% combined carbon (graphite added + infiltrated carbon)
This material delivers tensile strengths of 380-520 MPa depending on density and heat treatment, making it ideal for automotive gears, small engine components, power tool parts, and structural brackets where cost-effective strength is required.

Designing with FC-0208 material? Our engineering team provides free material selection guidance, including density recommendations, heat treatment options, and performance predictions for your specific loading conditions.
Get FC-0208 Material Consultation →
Material Composition & Specification
Standard Composition (MPIF Standard 35)
| Element | Nominal Content | Typical Range | Purpose |
|---|---|---|---|
| Iron (Fe) | Balance | 97.2-97.8% | Base material, structural strength |
| Copper (Cu) | 2.0% | 1.8-2.2% | Strengthening, machinability, corrosion resistance |
| Graphite (C) | 0.8% | 0.6-0.9% | Hardenability, wear resistance |
| Other Elements | <0.5% | — | Lubricants, trace impurities |
Copper Addition Benefits:
- ✓ Increases tensile strength 25-35% vs. straight iron
- ✓ Improves sinterability (liquid phase sintering at Cu melting point)
- ✓ Enhances machinability (copper acts as lubricant during cutting)
- ✓ Provides modest corrosion resistance (copper protective layer)
Carbon Addition Benefits:
- ✓ Enables heat treatment response (carburizing, case hardening)
- ✓ Improves wear resistance (forms iron carbides)
- ✓ Increases hardness after heat treatment
Mechanical Properties by Density
As-Sintered Properties (No Heat Treatment)
| Density Grade | g/cm³ | % Theoretical | Tensile Strength | Yield Strength | Elongation | Hardness |
|---|---|---|---|---|---|---|
| Low Density | 6.6-6.8 | 84-87% | 310-380 MPa | 220-280 MPa | <1% | 50-65 HRB |
| Medium Density | 6.9-7.1 | 88-90% | 380-450 MPa | 280-340 MPa | 1-2% | 60-75 HRB |
| High Density | 7.2-7.4 | 92-94% | 450-520 MPa | 340-400 MPa | 2-3% | 70-85 HRB |
Density Selection Criteria:
- Low density (6.6-6.8 g/cm³): Cost-optimized for static loads, bushings, low-stress brackets
- Medium density (6.9-7.1 g/cm³): Standard for most applications, good strength/cost balance
- High density (7.2-7.4 g/cm³): Higher strength, better fatigue resistance, wear applications
Heat-Treated Properties (Quench + Temper)
Typical Heat Treatment: Oil quench from 870°C + temper at 200°C
| Density Grade | Tensile Strength | Yield Strength | Hardness | Impact Strength |
|---|---|---|---|---|
| 6.6-6.8 g/cm³ | 480-580 MPa | 420-520 MPa | 25-35 HRC | 3-5 J (Charpy) |
| 6.9-7.1 g/cm³ | 580-680 MPa | 520-620 MPa | 30-40 HRC | 3-6 J |
| 7.2-7.4 g/cm³ | 680-780 MPa | 620-720 MPa | 35-43 HRC | 4-7 J |
Heat Treatment Benefits:
- ✓ 50-70% increase in tensile strength
- ✓ Significant hardness increase (HRB →HRC range)
- ✓ Improved wear resistance
- ✓ Enhanced fatigue life (40-60% improvement)
Limitations:
- ⚠️ Ductility decreases (elongation drops to <1%)
- ⚠️ Adds $0.30-$0.80 per part processing cost
- ⚠️ May cause distortion (requires sizing/grinding)
Fatigue & Dynamic Properties
Fatigue Strength (Rotating Bending)
| Density | As-Sintered Fatigue Limit | Heat-Treated Fatigue Limit | Test Cycles |
|---|---|---|---|
| 6.8 g/cm³ | 140-170 MPa | 220-260 MPa | 10⁶ cycles |
| 7.1 g/cm³ | 170-210 MPa | 260-310 MPa | 10⁶ cycles |
| 7.4 g/cm³ | 210-250 MPa | 310-370 MPa | 10⁶ cycles |
Fatigue Performance Factors:
- Higher density = longer fatigue life (reduced stress concentration at pores)
- Surface densification improves fatigue strength 30-50%
- Shot peening adds 20-40% fatigue life improvement
Wear Resistance
Sliding Wear Performance (Pin-on-Disk Test):
| Material Condition | Wear Rate (mm³/Nm) | Coefficient of Friction | Applications |
|---|---|---|---|
| As-Sintered | 2.5 - 4.0 × 10⁻⁶ | 0.35 - 0.45 | Bushings with lubrication |
| Heat-Treated | 1.2 - 2.0 × 10⁻⁶ | 0.25 - 0.35 | Gears, sliding contacts |
| Case Hardened | 0.5 - 1.0 × 10⁻⁶ | 0.20 - 0.30 | High-wear applications |
Wear Improvement Methods:
- Steam treatment (creates Fe3O4surface layer, fills surface porosity)
- Case carburizing + hardening (increases surface hardness to 58-62 HRC)
- Resin/oil impregnation (fills porosity, reduces friction)
Physical & Thermal Properties
Physical Characteristics
| Property | Value | Units | Notes |
|---|---|---|---|
| Density Range | 6.6 - 7.4 | g/cm³ | Varies with compaction pressure |
| Theoretical Density | 7.85 | g/cm³ | 100% dense wrought steel |
| Typical Porosity | 6-16% | vol% | Controlled interconnected pores |
| Permeability | 0-50 | millidarcies | Oil retention capability |
| Electrical Resistivity | 18-25 | µΩ·cm | Higher than wrought (porosity effect) |
| Magnetic Properties | Ferromagnetic | — | Suitable for magnetic applications |
Thermal Properties
| Property | Value | Units | Notes |
|---|---|---|---|
| Melting Point | 1,510 | °C | Pure iron base |
| Sintering Temperature | 1,120-1,150 | °C | Typical production range |
| Coefficient of Thermal Expansion | 11-13 | 10⁻⁶/°C | @ 20-200°C |
| Thermal Conductivity | 25-35 | W/(m·K) | Lower than wrought (porosity) |
| Specific Heat | 450-480 | J/(kg·K) | @ room temperature |
Thermal Processing Recommendations:
- Sintering atmosphere: Dissociated ammonia, nitrogen-hydrogen, or vacuum
- Cooling rate: <100°C/min to avoid cracking
- Annealing (stress relief): 550-650°C for 1-2 hours
Corrosion Resistance
Performance in Various Environments
| Environment | Corrosion Rate | Rating | Protection Methods |
|---|---|---|---|
| Indoor Dry Air | <0.5 µm/year | ✓ Excellent | None required |
| High Humidity (85% RH) | 5-15 µm/year | ⚠️ Fair | Oil coating recommended |
| Salt Spray (5% NaCl) | 50-150 µm/year | ✗ Poor | Plating or coating required |
| Industrial Atmosphere | 10-25 µm/year | ⚠️ Fair | Oil, paint, or phosphate coating |
| Automotive Underbody | 20-50 µm/year | ⚠️ Fair | Electroplating (Zn, Ni) essential |
Corrosion Protection Options:
- Steam Treatment - Black oxide (Fe3O4 layer, fills surface pores →+50-70% corrosion resistance
- Oil Impregnation - Fills porosity with rust-preventive oil →+100-150% resistance
- Electroplating - Zinc, nickel, or chromium plating →+10-20× resistance
- Resin Impregnation - Epoxy fills pores, seals surface →+200-400% resistance
- Powder Coating - Organic coating after resin seal →Maximum protection
Note: Copper content provides modest galvanic protection but insufficient for harsh environments.
Machinability & Secondary Operations
Machining Characteristics
| Operation | Machinability Rating | Recommended Tools | Feed/Speed |
|---|---|---|---|
| Turning | 80-90% of B1112 steel | Carbide, HSS | 120-180 m/min (carbide) |
| Drilling | 75-85% of B1112 | Carbide-tipped drills | 0.15-0.25 mm/rev feed |
| Tapping | 70-80% of B1112 | Form taps preferred | Cutting oil essential |
| Grinding | Good | Aluminum oxide wheels | Standard parameters |
| Broaching | Fair to Good | HSS broaches | Lower speeds recommended |
Machinability Factors:
- ✓ Copper content improves chip breaking and tool lubrication
- ✓ Lower hardness (as-sintered) enables easier machining than heat-treated
- ⚠️ Porosity causes abrasive tool wear (tool life 60-80% of wrought steel)
- ⚠️ Interconnected porosity can absorb cutting fluids (use minimal flood cooling)
Cost-Saving Tip: Design parts to minimize secondary machining. Every machined feature adds $0.10-$0.50 per part cost.
Design Guidelines for FC-0208
Optimal Design Features
✓Good Design Practices:
- Cylindrical or prismatic shapes with uniform wall thickness
- Gears with straight or helical teeth (helix angle <15°)
- Holes parallel to pressing direction (cored during compaction)
- Chamfers and radii along pressing axis (no sharp corners)
- Wall thickness 2.0-8.0 mm (thinner requires higher density)
✗Design Challenges:
- Undercuts perpendicular to pressing direction (require machining)
- Internal threads (must be tapped after sintering)
- Very thin walls <1.5 mm (risk cracking, low fill density)
- Large flat areas (prone to density variation)
- Sharp internal corners (stress concentrations with porosity)
Recommended Design Tolerances
| Feature Type | Achievable Tolerance | Notes |
|---|---|---|
| Outer Diameter | ±0.08 - 0.12 mm | After sizing operation |
| Inner Diameter | ±0.10 - 0.15 mm | Cored holes, better than drilled |
| Length/Height | ±0.10 - 0.20 mm | Perpendicular to pressing direction |
| Flatness | 0.05 - 0.10 mm | On faces perpendicular to pressing |
| Parallelism | 0.08 - 0.15 mm | Between pressed faces |
| Concentricity | 0.10 - 0.20 mm | Between OD and ID |
Tighter Tolerances Available:
- Sizing operation improves OD/ID to ±0.03-0.05 mm (adds $0.15-$0.30/part)
- Grinding achieves ±0.01-0.02 mm (adds $0.50-$1.50/part)
Applications & Case Studies
Common Applications
Automotive Industry:
- Transmission gears (spur, helical <15°)
- Oil pump rotors and gears
- Small engine connecting rods (lower-stress variants)
- Synchronizer hubs
- Structural brackets and mounts
Power Tools:
- Planetary gear carriers
- Motor mounts and brackets
- Clutch components
- Drive gears
Industrial Machinery:
- Conveyor system gears
- Actuator components
- Lock mechanisms
- Cam followers and bushings
Small Engines (Lawn & Garden):
- Camshafts
- Rocker arms
- Crankshaft gears
- Governor components
Case Study: Automotive Transmission Gear
Application: 3-speed automatic transmission parking gear Requirements:
- Tensile strength >450 MPa
- Hardness 75-85 HRB
- Gear tooth profile tolerance ±0.08 mm
- Cost target <$2.50/part (100K volume)
Solution: FC-0208 Material Selection
- Density: 7.1 g/cm³ (90% theoretical)
- Condition: As-sintered (no heat treatment)
- Cycle time: 18 seconds per part
Results:
- ✓ Achieved tensile strength: 465 MPa
- ✓ Hardness: 78 HRB (specification met)
- ✓ Dimensional accuracy: ±0.10 mm (within tolerance)
- ✓ Production cost: $2.15/part (15% under target)
- ✓ Zero secondary machining required (near-net-shape)
Cost Comparison:
- Forged + machined alternative: $6.80/part
- Savings: $464,000/year at 100K volume (68% cost reduction)
Cost Analysis
Material & Processing Costs (Estimated USD per Part, 50K Volume)
| Cost Component | 6.8 g/cm³ | 7.1 g/cm³ | 7.4 g/cm³ |
|---|---|---|---|
| Raw Powder | $0.80 | $0.95 | $1.10 |
| Compaction | $0.40 | $0.45 | $0.55 |
| Sintering | $0.30 | $0.30 | $0.35 |
| Sizing (optional) | +$0.20 | +$0.20 | +$0.20 |
| Heat Treatment (optional) | +$0.50 | +$0.60 | +$0.70 |
| Steam Treatment (optional) | +$0.08 | +$0.08 | +$0.10 |
| Total (as-sintered) | $1.50 | $1.70 | $2.00 |
| Total (with HT) | $2.00 | $2.30 | $2.70 |
Tooling: $15,000-$40,000 (500K-2M part life) = $0.01-$0.08/part amortized
Quality Control & Testing
Standard QC Tests
| Test | Frequency | Specification | Method |
|---|---|---|---|
| Density | Every batch | ±0.05 g/cm³ of target | MPIF 42 (Archimedes) |
| Tensile Strength | 1 per 5,000 parts | Per specification table | MPIF 10 |
| Hardness | 1 per 1,000 parts | ±5 HRB of target | ASTM E18 (Rockwell) |
| Dimensional | 1 per 500 parts | Per drawing tolerances | CMM or optical |
| Microstructure | Weekly | Porosity rating 1-4 | Metallographic section |
Material Certifications Available:
- Chemical composition analysis (C, Cu, Fe)
- Mechanical property test reports
- Dimensional inspection reports (FAI)
- Traceability to powder lot numbers
Storage & Handling
Material Storage Guidelines
Powder Storage:
- Keep containers sealed to prevent moisture absorption
- Store in cool, dry environment (<30°C, <50% RH)
- Shelf life: 12 months (powder), 24 months (sintered parts)
- Avoid contamination with other powders or foreign materials
Finished Part Storage:
- Oil-treated parts: store in dry conditions, no special packaging
- Untreated parts: apply rust-preventive oil or VCI bags
- Stacking: use separators to prevent surface damage
- Shelf life: Indefinite (with proper corrosion protection)
Get FC-0208 Material Expertise
Selecting the optimal density, heat treatment, and secondary operations for FC-0208 requires understanding your specific load conditions and cost targets. Our materials engineering team provides:
✓Free Material Consultation - Density and heat treatment recommendations ✓Property Predictions - Expected strength/hardness for your design ✓Cost Optimization - Balancing performance vs. processing costs ✓Design Review - Manufacturability assessment for FC-0208 production
Request FC-0208 Engineering Support →
Response Time: Material recommendations within 24 business hours Testing: MPIF-standard test reports available for all production lots
Internal Links
- FC-0205 Material Properties - Lower carbon variant for ductility
- FN-0405 High-Strength Material - Nickel-strengthened alternative
- Powder Metallurgy Material Selection Guide - Compare all PM material options
- Automotive PM Applications - FC-0208 success stories in automotive
- Powder Metallurgy Process Guide - How FC-0208 parts are manufactured
Frequently Asked Questions
What's the difference between FC-0205 and FC-0208 materials?
FC-0205 contains 0.5% combined carbon vs. 0.8% in FC-0208. This makes FC-0205 slightly lower strength (350-420 MPa) but better for applications requiring cold forming or high ductility. FC-0208 offers 15-20% higher strength and better hardenability for heat-treated components.
Can FC-0208 be welded?
Not recommended. Powder metallurgy parts contain interconnected porosity that causes welding defects (porosity, cracking). For assemblies, use mechanical fastening, brazing, or adhesive bonding instead.
How does FC-0208 compare to FN-0205 (iron-nickel)?
FN-0205's advantage is not as-sintered strength (280-480 MPa, similar to FC-0208) but toughness and heat-treatment response: as FN-0205HT it reaches 620-1,280 MPa versus 450-720 MPa for FC-0208HT, and it costs 25-35% more. Choose FN-0205 for high-stress or impact-loaded applications (connecting rods, high-torque gears), especially when heat treatment is planned. FC-0208 suits cost-sensitive, medium-stress applications.
What surface treatments improve corrosion resistance?
Best options: (1) Steam treatment + oil impregnation for indoor use, (2) Zinc electroplating for automotive underbody, (3) Resin impregnation + powder coating for maximum protection. Steam treatment alone provides 50-70% improvement at minimal cost.
Can FC-0208 be used for bearings?
Yes, with modifications. Use lower density (6.6-6.8 g/cm³) for self-lubricating bushings where porosity retains oil. Add oil impregnation (10-15% oil by weight) for improved bearing performance. Not suitable for high-speed or high-load bearings (use bronze PM alloys instead).
Standards & References
Grade designations and material property data on this page follow published powder metallurgy industry standards. Current editions are available from the publishers:
- MPIF Standard 35 — Materials Standards for PM Structural Parts — Metal Powder Industries Federation (MPIF)
- ASTM International — metal powder and PM material specifications — ASTM International
- ISO 5755 — Sintered metal material: Specifications — ISO
For critical applications, always verify grade data against the current edition of the applicable standard and your part-specific validation requirements.
Expert Review
Yao Qingpu
Powder Metallurgy Manufacturing Expert at SinterWorks PM
Yao Qingpu works with global buyers on powder metallurgy design review, material selection, tolerance planning, cost-down opportunities, and production feasibility. His experience covers PM gears, automotive components, structural parts, and practical DFM support for long-run manufacturing programs.
Related Resources
Use these internal links to keep moving through the most relevant guides, service pages, and technical references for this topic.
What Is Sintered Metal?
The process behind every FC-0208 part: powder, press, furnace.
FC-0205 Material Guide
Compare FC-0208 with a lower-carbon FC-series material when balancing strength, wear, and cost.
Materials Overview
See where FC-0208 fits within broader FC-, FN-, stainless, and bearing material families.
Hydraulic Pump Gears
Review one application where FC-0208 can be practical depending on pressure target and finishing route.
Request a Quote
Send your drawing and duty condition for FC-0208 material review and quotation support.
